Three-Tier Single-Door Vacuum Oven

Name: 21700 Cylindrical Cell Can
Brand: Canrd
Price: 66.45 USD
Availability: InStock

Model：

CAN-OVE22-0850ST

Applied range：

Suitablefor lithium ion battery pole piece, battery core, to be injected liquid battery baking. Door opening mode: single door; Elastic double-layer glass door, three-layer pressure detection, overpressure protection; Inner liner sealing ring is made of silicone rubber O-ring by pouring mold, which is high temperature resistant and corrosion resistant.

Date issued：

2024-12-27 03:50:32

Equipment Size：

L850mm* W1270mm * H2000mm

Weight：

800kg

Details

Overview

Specifications

Details

This product is a three-layer single-door vacuum oven designed for critical drying and baking processes in battery manufacturing lines, including prismatic aluminum case, cylindrical, pouch cell, solid-state, and dry electrode preparation setups. It features a compact multi-layer configuration that allows efficient batch processing while maintaining uniform vacuum and temperature conditions. The oven is built to support moisture-sensitive electrode materials and cell components, contributing to improved electrochemical stability and processing consistency. Typical applications include drying of coated electrodes, electrolyte removal, and thermal treatment of battery precursor materials under controlled vacuum. With its robust construction and reliable sealing, the CAN-OVE22-0850ST offers a practical solution for research-scale or pilot production environments where precise thermal and vacuum control is essential.

gas source	dry gas 0.1-0.2Mpa/vacuum -0.098-0.1Mpa/compressed gas 0.4-0.5Mpa
power	about 9kW
equipment size	L850mm * W1270mm * H2000mm
service environment	regular environment
studio size per floor	L450mm × W800mm × H350mm
power supply	AC:380V, 50HZ
Equipment Weight	800kg

Temperature Uniformity	Each point of the inner cavity 50MM from the wall: ≤ 3.5 ℃ under vacuum and ≤ 2.5 ℃ under normal pressure
Serial Temperature	≤ 20 ℃ (within 100 degrees of adjacent layer temperature, only within 20 degrees higher than room temperature)
Vacuum Degree	-0.1 ~-0.098Mpa, 24-hour digital holding pressure ≥ 95%
Thermal Insulation Performance	The temperature of the outer wall shall not exceed 45 degrees (except glass doors)
Temperature range	Room temperature ~ 150 ℃
Vacuum pumping and nitrogen filling position and interface specification	The interface position is at the rear of the equipment; The vacuum pumping interface is DN20, and the dry gas filling interface is ￠ 12mm air pipe interface.
display error	set value and stable table display value ≤ ± 0.1 ℃
response speed	table display reaches the set value within 30 minutes, no-load core temperature stabilization time is 45-60 minutes
