Standard NCM electrode sheet/roll

$30203.78

Name

Specifications

✓ Selected: Standard NCM pole piece/roll / Please contact us for a quote

Quantity

Quality Assurance

Factory Direct

Global Shipping

Details

Overview

Specifications

Details

This product is designed for researchers and developers working with high‑energy cathode materials, offering standard NCM811 pole pieces in both small electrode and roll formats. Fabricated on 12‑µm aluminum foil with an active material loading between 80% and 95%, these electrodes provide a consistent areal density ranging from 5 to 25 mg/cm² and a material‑specific capacity of 188 mAh/g. The two formats differ in compaction density—1.1–1.5 g/cm³ for small electrodes versus 2.5–3.0 g/cm³ for rolls—allowing users to select the appropriate structure for half‑cell testing, pouch‑cell assembly, or larger‑scale electrode evaluation. The standard NCM pole piece/roll is a reliable basis for electrochemical characterization, cycle‑life studies, and quality‑control experiments in advanced battery research.

For specific pricing, please contact us for a quotation.

Item	Small Electrode Sheet	Electrode Roll
Material	NCM811	NCM811
Loading	80.0–95.0%	90.0–95.0%
Areal Density	5–25 mg/cm²	8–25 mg/cm²
Compacted Density	1.1–1.5 g/cm³	2.5–3.0 g/cm³
Specific Capacity	188 mAh/g	188 mAh/g
Current Collector Foil Thickness	Aluminum Foil, 12 μm	Aluminum Foil, 12 μm
Current Collector Areal Density	3.3 mg/cm²	3.3 mg/cm²
