Silicon dioxide (1600)

$120.82

Model：

MA-EN-AN-0027

item_No

Specifications

Price

MA-EN-AN-002701

Silicous oxide (1600) 20g

$120.82

Details

Overview

Specifications

Details

This product is developed for use as a high-capacity anode material in lithium-ion batteries, featuring silicon oxide coated with carbon via chemical vapor deposition. It delivers a reversible capacity of up to 1600 mAh/g in initial half-cell tests, making it relevant for advanced energy storage research targeting higher energy densities. The material requires sealed storage, and testing is recommended using carbon-coated copper foil with NCM electrolyte under specified baking conditions. Physical and chemical properties, along with half-cell performance data, are provided to support evaluation. Available in quantities from 20 g to 1000 g, it is suited for laboratory-scale investigation and development of next-generation anode systems.

The material needs to be sealed and stored

It is recommended to use carbon coated copper foil for half cell testing

The electrolyte used during testing is NCM electrolyte (KLD-1230C)

Baking conditions for electrode: Bake at 85 ℃ for 4 hours

Lithium ion anode electrode material, coated with carbon by CVD, with a reversible capacity of up to 1600mAh/g for the first time.

Physical and chemical properties

No.	Test Item			Unit	Specification	Test Result
1	Physical Properties	Particle Size Distribution	D10	(μm)	3.0±1.0	3.42
2			D50	(μm)	6.0±1.0	5.38
3			D90	(μm)	≤10.0	8.64
4		BET		(m²/g)	1.5±0.2	1.58
5		TD		(g/cm³)	1.1±0.2	1.16
6	Electrochemical Performance	First Reversible Capacity		(mAh/g)	≥1550.0	1650.5
7	Electrochemical Performance	First Coulombic Efficiency		(%)	≥77.0	79.7
