Nickel Cobalt Manganese NCM523

1. Nickel Cobalt Manganese three-element material NCM523, with a monocrystalline structure, suitable for 4.35v high voltage applications, stable structure, good high-temperature storage performance, high specific capacity, high initial efficiency, high compact density, and excellent cycling performance.

2. Excellent processing performance, commercially produced in large quantities, good quality, and stable quality.

3. Widely used in electric tools, tablets, electronic toys, electric vehicles, and energy storage products.

4. Convenient for pouch cells and coin cells research.

---

1. A highly mature NCM material, the use of polycrystalline three-element material is relatively simple, with a compact density > 3.4g/cc.

2. For monocrystalline NCM523, due to the poor electronic conductivity of the material, the electrode formulation needs to be optimized (specifically consult Science Road's technology).

---

1. Storage conditions: sealed and stored at room temperature.

2. Shelf life: 2 years from the production date.

---

1. Highly mature ternary materials, polycrystalline ternary materials are simpler to use, compaction density >3.4g/cc

2. For monocrystalline NCM523, due to the poor electronic conductivity of the material, it is necessary to optimize the formula of the pole piece (consult with Canrd for details).





The cathode material of lithium cobalt acid battery is LiCoO2, and the ternary material is Li(NiCoMn)O2, ternary

composite cathode material precursor products are made of nickel salt, cobalt salt and manganese salt, and the

proportion of nickel, cobalt and manganese in it can be adjusted according to the actual needs, and the batteries

with the ternary material as cathode are more secure than lithium cobalt acid battery, and the lithium cobalt acid

and the ternary materials are good lithium battery cathode materials, but their chemical characteristics are different.

Both lithium cobaltate and ternary materials are good cathode materials for lithium batteries, but their chemical

properties are different, therefore, for their different chemical properties, the application fields are also different.

The cathode material of lithium cobalt acid battery is LiCoO2, and the ternary material is Li(NiCoMn)O2, ternary

composite cathode material precursor products are made of nickel salt, cobalt salt and manganese salt, and the

proportion of nickel, cobalt and manganese in it can be adjusted according to the actual needs, and the batteries

with the ternary material as cathode are more secure than lithium cobalt acid battery, and the lithium cobalt acid

and the ternary materials are good lithium battery cathode materials, but their chemical characteristics are different.

Both lithium cobaltate and ternary materials are good cathode materials for lithium batteries, but their chemical

properties are different, therefore, for their different chemical properties, the application fields are also different.
