Cylindrical battery grooving machine (manual)

Model：

CAN-CHA0A-2800DM

Applied range：

Itis suitable for uniform automatic rolling of cylindrical steel shells (or capacitor aluminum shells) equipped with batteries. The replacement of rolling molds can be applied to the production of cylindrical batteries of various specifications. Cylindrical lithium battery experimental equipment for cylindrical battery rolling machines.

Date issued：

2024-12-01 20:59:50

Equipment Size：

L780mm*W260mm* H450mm

Weight：

48kg

Details

Overview

Specifications

Details

This product is a manual cylindrical battery grooving machine developed for the precision processing of battery casings in cylindrical battery production lines. Designed for research and small-batch manufacturing environments, it supports the formation of consistent groove dimensions required for sealing and assembly processes. The Canrd CAN-CHA0A-2800DM model integrates manual operation with reliable mechanical control, offering a compact form factor suitable for laboratory or pilot-scale use. Its construction emphasizes stability and repeatability, making it a practical tool for evaluating cell designs or conducting limited production runs without full automation.

Equipment Size	L780mm * W 260mm * H450mm
Compressed Air	0.3~0.6MPa
Site Bearing	/
Appearance color	Grey-white RAL9006 (user can specify color, color plate is required)
Operating Environment	regular Environment
Power	About 300W
Power Supply	AC:220V, 50HZ
Equipment Weight	48kg

Standard configuration	Can be configured for 18650 series cylindrical batteries. It can also be equipped with 26650 and 21700 molds to make other types of batteries
machining accuracy	± 0.05mm
compatible products	18650, 26650, 21700, 26700
roll groove upper shoulder	3.8~6.5mm (adjustable)
motor speed	≤ 2800r/min (adjustable)
Roll groove depth	0~3.0mm (adjustable)

& nbsp; & nbsp; & nbsp; It is suitable for uniform automatic rolling of cylindrical steel shell (or capacitor aluminum shell) equipped with battery core. The replacement of rolling die can be applied to the production of cylindrical batteries of various specifications. Cylindrical lithium battery experimental equipment for cylindrical battery rolling machine.

1. the size of the rolling groove is adjustable
