Bare nickel cobalt manganese oxide lithium Ni900604 polycrystalline (uncoated)

Name: Bare nickel cobalt manganese oxide lithium Ni900604 polycrystalline (uncoated)
Brand: Canrd
Price: 40.78 USD
Availability: InStock

$40.78

Model：

MA-EN-CA-0059

item_No

Specifications

Price

MA-EN-CA-005901

20g

$40.78

Details

Overview

Specifications

Details

This product is a bare nickel cobalt manganese oxide lithium (Ni900604) polycrystalline cathode material, uncoated, developed for advanced lithium-ion battery research. As a high-nickel (Ni90) composition, it offers high energy density potential but requires strict moisture control throughout handling and processing due to its strong hygroscopic nature. Vacuum-sealed storage is recommended, and electrode preparation involves baking at 85 °C for 4 hours. Testing is typically performed with NCM electrolyte (KLD-1230C) in half-cell configurations using CC-CV charging and DC rate discharge protocols. The material's polycrystalline structure and uncoated surface make it suitable for studying intrinsic electrochemical behavior and degradation mechanisms in high-nickel cathodes, supporting efforts in next-generation battery development for electric vehicles and energy storage systems.

The material needs to be vacuum sealed for storage

The material is highly absorbent, and humidity control is required throughout the entire production process

The electrolyte used during testing is NCM electrolyte (KLD-1230C)

Baking conditions for electrode: Bake at 85 ℃ for 4 hours

Lithium ion cathode electrode material, which is an uncoated Ni90 polycrystalline material, is difficult to process and requires strict control of moisture content

Physical and chemical properties
Serial Number	Test items			Units	Specifications	Measured results	Inspection method or instrument
1	Chemical composition	Li2CO3		(wt%)	0.2~1.0	0.554	ICP
2		LiOH		(wt%)	0.2~1.0	0.528
3		Fe		(ppm)	≤50.0	14.0
4		Mg		(ppm)	≤100.0	22.0
5		Cu		(ppm)	≤20.0	2.3
6		Na		(ppm)	≤500.0	345.0
7		Ca		(ppm)	≤20.0	14.6
8		S		(ppm)	≤5000	4632.0
11	Physical Properties	Particle size distribution	D10	(μm)	≥10.0	11.552	Laser particle size analyzer
12			D50	(μm)	12.0~13.5	12.456
13			D90	(μm)	≤16.0	14.660
14		BET		(m2/g)	≥0.15	0.26	Automatic specific surface and porosity analyzer
15		Moisture		(ppm)	≤500	354.0	Moisture Analyzer
16	Electrochemical Performance	First discharge capacity		(mAh/g)	≥190.0	193.4	CR2032 0.1/0.1C(4.3-3.0V)
17	Electrochemical Performance	First Time Efficiency		(%)	≥83.0	85.0	CR2032 0.1/0.1C(4.3-3.0V)
