Details
Purchase the corresponding size of grinding balls when purchasing a ball mill jar. See the details in the figure below.
| Agate Ball Mill Jar Capacity | Agate Grinding Ball Size Combination | Mixing Ratio (Total Weight) | Mixing Rule |
| 25 ml | 3 mm / 5 mm / 8 mm | 50% : 30% : 20% (Total 20 g) | Standard 1/3 of jar capacity by weight |
| 50 ml | 5 mm / 8 mm / 10 mm | 50% : 30% : 20% (Total 50 g) | Standard 1/3 of jar capacity by weight |
| 100 ml | 5 mm / 8 mm / 10 mm | 50% : 30% : 20% (Total 75 g) | Standard 1/3 of jar capacity by weight |
| 150 ml | 5 mm / 8 mm / 10 mm | 50% : 30% : 20% (Total 100 g) | Standard 1/3 of jar capacity by weight |
| 250 ml | 5 mm / 8 mm / 10 mm | 50% : 30% : 20% (Total 200 g) | Standard 1/3 of jar capacity by weight |
| 300 ml | 5 mm / 8 mm / 10 mm | 50% : 30% : 20% (Total 225 g) | Standard 1/3 of jar capacity by weight |
| 500 ml | 5 mm / 10 mm / 15 mm | 50% : 30% : 20% (Total 300 g) | Standard 1/3 of jar capacity by weight |
| 1000 ml | 10 mm / 15 mm / 20 mm | 50% : 30% : 20% (Total 600 g) | Standard 1/3 of jar capacity by weight |
| Specification | Outer Diameter (mm) | Inner Diameter (mm) | Outer Height (mm) | Inner Depth (mm) | Lid Height (mm) | Total Height (mm) |
| 25 ml | 50 | 34 | 40 | 30 | 8 | 48 |
| 50 ml | 65 | 45 | 49 | 37 | 8 | 57 |
| 100 ml | 73 | 53 | 62 | 52 | 8 | 70 |
| 150 ml | 90 | 62 | 70 | 55 | 10 | 80 |
| 250 ml | 100 | 75 | 80 | 70 | 10 | 90 |
| 300 ml | 102 | 80 | 82 | 71 | 12 | 94 |
| 400 ml | 104 | 83 | 92 | 80 | 8 | 100 |
| 500 ml | 106 | 86 | 100 | 90 | 10 | 110 |
| 1000 ml | 135 | 105 | 126 | 111 | 15 | 141 |
| 2000 ml | 156 | 130 | 170 | 150 | 15 | 185 |
| 3000 ml | 165 | 140 | 200 | 180 | 15 | 215 |
Function: It can process ultra-fine materials with a narrow particle size distribution in a short time.
Features: Smooth appearance, high hardness, good toughness, impact resistance, resistance to various solvents (such as acetone, alcohol), high wear resistance, no contamination of products, long service life, high grinding efficiency, easy sealing and opening, tight sealing, thick tank wall, sturdy and durable. It will not have issues such as gaps and leaks during use.
Application: Widely used in precious metals, electronic ceramics, magnetic materials, pigments, coatings, and other industries.
