Rich Lithium Manganese Base-D

Name: PTFE groove mold
Brand: Canrud
Price: 90.61 USD
Availability: InStock

$45.31

Model：

MA-EN-CA-0071

item_No

Specifications

Price

MA-EN-CA-007101

20g

$45.31

Details

Overview

Specifications

Details

This product is a rich lithium manganese-based cathode material developed for high-energy-density lithium-ion battery research. It offers a wide voltage range and an initial discharge capacity exceeding 230 mAh/g (measured 250.0 mAh/g) with an initial efficiency of 80.0%. The material features controlled particle size distribution (D50 ~7.1 μm) and low moisture content (≤800 ppm), but is highly hygroscopic and requires vacuum-sealed storage and strict humidity control throughout handling. Optimal electrochemical performance is achieved using a 5V high-voltage electrolyte (KLD-5V06), and electrode preparation involves baking at 85°C for 4 hours. This material is suitable for advanced cathode development targeting improved energy density and voltage stability in experimental and prototype cells.

The material needs to be vacuum sealed for storage

The material is prone to water absorption, and humidity control is required throughout the entire production process

The electrolyte used during testing is 5V high-voltage electrolyte (KLD-5V06)

Baking conditions for polarizer: Bake at 85 ℃ for 4 hours

Lithium ion cathode electrode material has the characteristics of high energy density and wide voltage range

Physical and chemical properties

Test Items		Unit	Specilication	Measured Result	Test Method or Instrmment
Chemical Composition	Li	(wt%)	9.0±1.0	9.55	ICP
	Me	(wt%)	53.0±1.0	53.1	Me represents the total metallic content of nickel, cobalt, and manganese; the specific nickel-cobalt-manganese ratio is unknown and subject to technical confidentiality.
	Na	(ppm)	≤300	182.0	ICP
	Ca	(ppm)	≤150	62.2
	Fe	(ppm)	≤50	28.6
	Cu	(ppm)	≤25	6.2
	Zn	(ppm)	≤25	2.1
	S	(ppm)	≤3000	2012.8
	Magnetic Substances	(ppb)	≤50	14.8
Physical properties	D10	(μm)	≥3.0	6.622	Laser particle size analyzer
	D50	(μm)	7.0+1.4	7.082
	D90	(μm)	≤18.0	14.325
	BET	(m2/g)	1.0±0.5	1.05	Automatic specific surface area and porosity analyzer
	TD	（g/cm3）	≥1.4	1.62	Tap density meter
	PH	/	<12.0	11.62	pH meter
	Moisture content	(ppm)	≤800	402.0	Moisture analyzer
Elecuochemical perloumance	Iitial dascharge capacily	(mAh/g)	≥230.0	250.0	CR2032 0.1/0.1C(4.8-2.3V)
Elecuochemical perloumance	Initial efficiency	(%)	≥78.0	80.0	CR2032 0.1/0.1C(4.8-2.3V)
