Hydrogen-Oxygen Fuel Cell Membrane Electrode Assembly (MEA), Type 1

$302040.51

Numéro d'article:FM-EM-EL-000101

Spécifications

✓ Sélectionné: can be customized, consult customer service

Quantité

Assurance qualité

Vente directe usine

Livraison mondiale

Details

Aperçu

Détails

This hydrogen-oxygen fuel cell membrane electrode is designed for experimental and research applications in energy materials and fuel cell development. With a platinum loading of ≤0.4 mg/cm² (±5% tolerance) and a thickness of ≤30 μm, it achieves a low internal resistance of ≤1 mΩ and a power density exceeding 1.3 W/cm² at 2 A/cm² current density. The cathode demonstrates robust durability, with less than 5% performance loss after 30,000 voltage cycles and an anti-reversal time over 120 minutes. Available in active areas ranging from 1 cm² to 100 cm² for laboratory use, or in production-grade rolls up to 600 mm wide, this electrode supports customization to meet specific research needs. Pricing is based on custom requirements; please contact customer service for a tailored quotation. Note that returns are not accepted for non-quality-related issues.

the selling price is the anti-auction price. you can consult customer service to provide specific customization requirements, and then make a quotation after communication and confirmation.

Product Information
Product Name	Hydrogen-Oxygen Fuel Cell Membrane Electrode 1
Product Code	FM-EM-EL-0001
Platinum Loading	≤0.4mg/cm² (±5% tolerance)
Thickness	≤30μm
Internal Resistance	≤1mΩ
Power Density (0.4mg/cm² Pt)	At 2A/cm² current density, power density ≥1.3W/cm²
Cathode Durability	＜5% loss @2A/cm², after 30,000 voltage cycles, anti-reverse time ＞120 minutes
Experimental Grade	Active area available in different sizes from 1cm² to 100cm²
Production Grade	Maximum width 600mm
