Standard LFP Cathode Sheets and Rolls

Name: Membrane Electrode Assembly (MEA) Gas Diffusion Electrolytic Cell - Premium Version
Brand: Canrd
Price: 2410.29 USD
Availability: InStock

$30203.78

الاسم

المواصفات

✓ تم الاختيار: Standard LFP pole piece/roll / Please contact us for a quote

الكمية

ضمان الجودة

مباشرة من المصنع

الشحن العالمي

Details

نظرة عامة

مواصفات

تفاصيل

This product is designed for battery research and small-scale electrode production, offering both pre-cut small electrodes and continuous electrode rolls based on lithium iron phosphate (LFP) chemistry. The active material loading ranges from 90.0% to 97.0%, with a typical specific capacity of 150 mAh/g. The electrodes are coated on a 13 μm carbon-coated aluminum foil current collector, ensuring good adhesion and electrical contact. Surface density is adjustable between 4–20 mg/cm² for small electrodes and 6–18 mg/cm² for rolls, with compacted density values of 1.5–2.0 g/cm³ (single side) or 2.0–2.5 g/cm³ (double side). These specifications make the product suitable for evaluating LFP cathode performance in coin cells, pouch cells, or pilot-scale electrode fabrication, providing a consistent and customizable platform for materials characterization and battery assembly.

For specific pricing, please contact us for a quotation.

Project	Small Electrode	Electrode Roll
Material	Lithium Iron Phosphate - LFP	Lithium Iron Phosphate - LFP
Loading	90.0~97.0%	90.0~97.0%
Surface Density	4-20mg/cm2	6-18mg/cm2
Compacted Density	1.5-2.0g/cm3	1.5-2.0g/cm3 (single side) 2.0-2.5g/cm3 (double side)
Material Grams Capacity	150mAh/g	150mAh/g
Foil Thickness	Carbon-coated Aluminum Foil, 13um	Carbon-coated Aluminum Foil, 13um
Current Collector Surface Density	4.1mg/cm2	4.1mg/cm2
