Water Bath H-type Electrolytic Cell (Conventional/Sealed)

$78.53

Model：

CH2004（conventional），CH2004-S（sealed）

item_No

Specifications

Price

MA-CM-AE-002101

50ml

$78.53

Details

Overview

Specifications

Details

This product is a water bath H‑type electrolytic cell developed for electrochemical research and material characterization, particularly suited for experiments in energy materials and analytical electrode studies. The cell features a glass sand core partition that connects the two compartments, enabling controlled ion transport between working and counter electrode chambers. Its integrated water bath jacket allows precise temperature regulation, an essential parameter for reproducible kinetic and thermodynamic measurements. The cover is pre‑configured with three 6 mm electrode holes, with options to customize hole size and number based on specific electrode dimensions. Available in capacities from 50 mL to 250 mL, this cell supports both conventional and sealed configurations—the sealed version (CH2004‑S) is designed for experiments requiring an airtight environment. Please note that electrodes are not included; the unit is supplied as a standalone cell body with PTFE cap in the conventional type.

Note: The electrolytic cell cover has three 6mm electrode holes by default. The size and number of holes on the cover can be customized according to the electrode size purchased by the customer. Please inform us in advance. The electrode in the photo is for reference only.

Working electrode cell water bath temperature control

Glass sand core is used to connect the two cells

No electrode included, the electrodes in the picture are for reference only
