NMP Recovery System

Name: NMP Recovery System
Brand: Canrd
Availability: InStock

Model：

CAN-REC16-1000ST

Applied range：

Itis suitable for scientific research units to recycle NMP solvent in coating process and implement environmental protection emission standard: GB 30484-2013 "Emission Standard for Pollutants from Battery Industry" non-methane total diameter content standard.

Date issued：

2024-12-19 00:58:54

Equipment Size：

L1200mm* 800mm * H1000mm

Weight：

120kg

Details

Overview

Specifications

Details

This NMP recovery system, designed for integration across multiple battery production lines—including prismatic aluminum case, solid-state, metal lithium, cylindrical, pouch cell, and glovebox stacking setups—enables efficient solvent recycling during electrode fabrication. The CAN-REC16‑1000ST model is developed to capture and purify NMP (N‑methyl‑2‑pyrrolidone) vapors, reducing solvent consumption and emissions while maintaining process consistency. By recovering high‑purity NMP for reuse, the system supports cost reduction and environmental compliance in battery manufacturing. Its configuration is suitable for both pilot‑scale and larger production environments, particularly where strict solvent management is required. This equipment is engineered to align with the material handling and safety demands of advanced battery assembly lines.

spray tank volume	0.25 m³
solvent storage capacity	50L
power	1.87kW
power supply	380V/50Hz
treated air volume	1000 m/h

Centrifugal fan	power/voltage: 0.37KW/380V
pump in anti-corrosion tank	power/voltage: 0.75KW/380V

it is suitable for scientific research units to recycle NMP solvent in coating process and implement environmental protection emission standard: GB 30484-2013 "emission standard for pollutants from battery industry" non-methane total diameter content standard.

1. The equipment is fully automated to maintain stable NMP concentration and TVOCs content in exhaust air;

2. The equipment adopts two-stage spray adsorption design to ensure the stability and safety of the system operation, and the exhaust gas discharged meets the national and local environmental protection requirements;

3. Equipment composition: recovery tower, pump group, fan, ventilation pipe, NMP liquid storage tank and electric control system;

4. The recovery unit has high recovery rate, low operating cost, beautiful appearance, small footprint, superior performance and simple operation, and can be widely used in the coating link of lithium battery production line.
