LALZO (Aluminum-doped Lithium Lanthanum Zirconium Oxide) Solid-state Electrolyte (300nm)

$60.41

Model：

MA-EN-SS-0001

item_No

Specifications

Price

MA-EN-SS-000101

10g

$60.41

Details

Overview

Details

This product is designed for the development of advanced solid-state battery systems, specifically as a garnet-type oxide solid electrolyte. The LALZO material, with a nominal composition of Li6.28Al0.24La3Zr2O12, is produced via high-temperature calcination of precursors such as lithium carbonate, lanthanum oxide, and zirconium oxide. It offers high room-temperature ionic conductivity, stable electrochemical compatibility with metallic lithium, and a high oxidation potential, making it suitable for both pure inorganic all-solid-state batteries and polymer-based semi-solid-state configurations. The controlled particle size and dry-air calcination atmosphere support reproducible processing. Typical research applications include electrolyte layer fabrication, interfacial stability studies, and battery assembly for performance evaluation. This product is particularly relevant for laboratories focused on next-generation energy storage and solid-state electrolyte optimization.

LALZ0 chemical formula: Li6.28Al0.24La3Zr2O12

Characteristics: This product is made by high-temperature calcination of lithium carbonate, lanthanum oxide, zirconium oxide, etc. It has high room temperature ionic conductivity, stable towards metallic lithium, high oxidation potential, and controllable particle size.

Scope of application: Pure inorganic all-solid-state batteries, polymer semi-solid-state batteries

LALZO has a garnet crystal structure, and the high-temperature calcination atmosphere is dry air.

Scanning electron microscope images:
