Hard Carbon (Li-ion Battery) - B
Hard Carbon (Li-ion Battery) - B
Hard Carbon (Li-ion Battery) - B
Hard Carbon (Li-ion Battery) - B
Hard Carbon (Li-ion Battery) - B

Hard Carbon (Li-ion Battery) - B

$45.31
Model：
MA-EN-AN-0031
item_No
Specifications
Price
MA-EN-AN-003101
20g
$45.31

Details

Hard carbon capacity testing procedure recommendation: Rest 4h, 0.2C DC to 0V, 0.1C DC to 0V, 0.01C DC to 0V, 10μA DC to 0V, rest 3 min, 0.1C CC to 2V.

As a negative electrode material for lithium-ion batteries, it exhibits excellent rate performance and high/low temperature performance. Used in lithium-ion batteries and lithium-ion capacitors.

This product is biomass hard carbon.

Note:

1、CC - Constant Current Charging; DC - Constant Current Discharging; CV - Constant Voltage Charging

2、Recommended electrolyte: Graphite coin cell electrolyte (KLD - 1230C)

Commodity Encyclopedia

Suggested capacity test process for hard carbon: Rest for 4h, 0.2C DC to 0V, 0.1C DC to 0V, 0.01C DC to 0V, 10μA DC to 0V, rest for 3 min, 0.1C CC to 2V.
