Conductive carbon black LiTX200

Name: Conductive carbon black LiTX200
Brand: Canrd
Price: 30.21 USD
Availability: InStock

$30.21

Model：

MA-EN-CO-0020

item_No

Specifications

Price

MA-EN-CO-002001

20g

$30.21

Details

Overview

Specifications

Details

The Conductive carbon black LiTX200 is an experimental-grade additive developed specifically for lithium-ion battery electrodes, intended to enhance power density, energy density, and long-term cycling stability. Its unique morphology reduces solvent requirements during slurry preparation while maintaining high conductivity and stability across a range of operating conditions. The material supports higher solids loadings in electrodes, improves packing density, and promotes electrolyte distribution and transport, which collectively contribute to increased energy density and reduced production costs. It also maintains effective conductivity at low temperatures, extending battery performance under demanding conditions. Common applications include hybrid electric vehicles, tablets, smartphones, and power tools, where lightweight, high-energy-density, and durable batteries are required. This product is suitable for both cathode and anode formulations at loadings between 1% and 10%, depending on specific performance targets.

LITX 200 conductive additive is designed for lithium-ion batteries and is designed to provide superior power and energy density, as well as excellent long-term cycling stability.

This additive can be added to the cathode and anode electrodes of lithium-ion batteries in amounts between 1% and 10% depending on the application needs.

The unique morphology of LITX 200 conductive additive allows it to require less solvent than other additives in the preparation of electrode slurries.

Its high conductivity and stability make it ideal for lithium-ion battery applications that require high performance.

The addition of LITX 200 conductive additive to the electrode slurry can achieve the following effects:

1. Allow higher solids loadings, which means that the amount of active material in the electrode can be increased without increasing the total volume, thus increasing the energy density.

2. Reduce the amount of solvents and conductive additives required, which helps to reduce production costs and improve the energy density of the battery.

3. Provide higher packing density, which means that the electrode materials can be packed together more tightly, reducing the ineffective space and improving the energy density.

4. Promote the distribution and transport of electrolytes, which helps to improve the performance and cycle life of the battery.

5. Improve the performance of the battery at low temperatures, because LITX 200 conductive additive is able to maintain good conductivity, even at lower temperatures.

LITX 200 conductive additive is suitable for the following battery applications:

Hybrid electric vehicles: require batteries with high energy density and long cycle life to support longer driving distances.

2. Tablets: The battery should be lightweight, slim, and able to provide sufficient battery life.

3. Smartphones: Similar to tablets, smartphones also require a lightweight and long-lasting battery.

4. Power tools: High power output and stable performance batteries are required to support the operation of power tools.

No.	Test Item		Unit	Specification	Measured Result
1	Physical Properties	BET	(m²/g)	100.0~200.0	152.20
2		Oil Absorption	(ml/100g)	150.0~180.0	162.30
3		Iron (Fe)	(ppm)	＜800	250.0
4		Total Co, Cr, Cu, Mn, Ni	(ppm)	7.0~10.0	9.2
