Automatic coating machine (300mm)

Automatic coating machine (300mm)

Model：
CAN-COT50-0300DS
Applied range：
Thisproduct is widely used in all kinds of coating research, such as ceramic film, crystal film, battery material film, special nano film; can adapt to the future development of science and technology of film formation under high temperature conditions.
Date issued：
2024-12-08 18:03:48
Equipment Size：
L550mm× W310mm × H330mm
Weight：
50kg

Details

Vacuum plate size
L415mm × W310mm × H30mm
Equipment weight
50kg
Equipment size
L550mm × W310mm × H330mm
power supply
AC:2200V, 50HZ
coating speed
0~150mm/sec (such as lithium iron phosphate slurry)
coating width
standard 100mm(0~150mm customizable)
precision
10um
the adjustable range of scraper
0.02~3.5mm adjustable
coating drive
motor drive, stable and adjustable coating speed
coating method
flat plate coating, standard metering devices such as film making device or scraper
vacuum pump
oil-free vacuum pump with one built-in
stroke
The stroke can be adjusted by the travel switch between 0~300mm

& nbsp; & nbsp; & nbsp; This product is widely used in various film research


1. The coating speed is adjustable within the range of 0~150mm/sec;

2. Flat plate coating, motor-driven blade coating, stable and adjustable coating speed;

3. vacuum aluminum plate can quickly place or remove the substrate, etc.;

4. Adjustable stroke between 0~300mm;

5. With micron-level adjustable film applicator (scale 10um), a scraper with a width of 100mm;

6. Can be used in the glove box, easy to operate, small size, can save space;

7. Built-in vacuum pump, substrate adsorption without deformation and wrinkles;

8. Exquisite appearance, sheet metal using three-dimensional geometric design, simple and beautiful.
