Lithium-ion Battery Anode Electrode Sheet (SC Silicon-Carbon Anode SC02)
Lithium-ion Battery Anode Electrode Sheet (SC Silicon-Carbon Anode SC02)
Lithium-ion Battery Anode Electrode Sheet (SC Silicon-Carbon Anode SC02)
Lithium-ion Battery Anode Electrode Sheet (SC Silicon-Carbon Anode SC02)
Lithium-ion Battery Anode Electrode Sheet (SC Silicon-Carbon Anode SC02)
Lithium-ion Battery Anode Electrode Sheet (SC Silicon-Carbon Anode SC02)

Lithium-ion Battery Anode Electrode Sheet (SC Silicon-Carbon Anode SC02)

$75.51
✓ 選択中: No. SC02XX / 5 Pcs / Calendered
品質保証
工場直販
世界規模の配送

Details

This product is a silicon-carbon composite electrode sheet, designated as the SC02XX Si/C 420 Electrode, developed for use in battery research and component-level testing. It features a high active material loading of 95%, composed of 5% Si/C 1800 and 95% graphite, delivering a specific capacity of 420 mAh/g within a 0.005–2.000 V window and an areal capacity of 1.9 mAh/cm². The electrode is fabricated on a 9 μm carbon-coated copper foil current collector, with a coating areal density of 4.80 mg/cm². To achieve optimal electrochemical performance, it requires the use of Canrd’s recommended KLD-Si01 electrolyte and specified testing protocols, as variations in electrolyte or method may significantly alter results. Common applications include half-cell evaluation and full-cell assembly with compatible cathode models (e.g., SY13XX, LC02XX) at an N/P ratio of approximately 1.09. Storage under vacuum is recommended for up to six months, with use within one month after opening.
Canrd 10*10cm 5 sheets/pack   Coating
NO. Electrode Name Model Main Material Active Material Capacity (mAh/g) Loading Areal Density (mg/cm²) Areal Capacity (mAh/cm²)
1 NCA Electrode SY51 NCA-S (Nickel Cobalt Aluminum Oxide) 195  94.50% 17.66  3.25
2 Ni90 Electrode SY41 Ni90 Single Crystal NCM 195  94.50% 9.50  1.75
3 NCM811 Electrode SY33 NCM811 Single Crystal 188  94.50% 9.20  1.63
4 NCM811 Electrode SY34 — 188  94.50% 21.50  3.82
5 NCM622 Electrode SY25 NCM622 Single Crystal-B 168  96.70% 10.00  1.62
6 NCM622 Electrode SY24 — 168  96.70% 21.60  3.51
7 NCM523 Electrode SY15 NCM523 165  94.00% 19.70  3.06
8 NCM523 Electrode SY13 NCM523 165  94.00% 10.50  1.63
9 LCO Electrode LC02 High Voltage Lithium Cobalt Oxide-Z-4.45V 178  96.40% 10.00  1.72
10 LRM Electrode FL01 Lithium-rich Manganese-based-E 280  95.00% 5.96  1.59
11 Graphite Electrode SM02 Natural Graphite (Standard)-A 340  95.70% 5.80  1.89
12 Fast Charging Graphite Electrode SM04 Fast Charging Graphite-B 350  96.70% 5.60  1.90
13 Silicon Carbon Electrode SC02 Silicon Carbon Anode 1800 (Porous Carbon Deposited Silicon) 420  95.00% 4.80  1.92
14 NFM Electrode NT02 Sodium Nickel Iron Manganese Oxide 127  95.50% 12.27  1.49
15 NFM Electrode NT03 — 127  95.50% 8.00  0.97
16 Hard Carbon Electrode YT02 Imported Hard Carbon (5 μm) 300  95.50% 6.00  1.72
17 LFP Electrode LF07 Lithium Iron Phosphate
(High Compaction Density)		 150  91.50% 12.30  1.69
18 LNMO Electrode NM01 High Voltage Lithium Nickel Manganese Oxide-B 130  96.00% 7.50  2.00
19 NFPP Electrode NF01 Sodium Iron Phosphate Pyrophosphate 100  93.50% 15.30  1.43
20 Vanadium Pentoxide Electrode VO02 Vanadium Pentoxide 300  80.00% 5.00  1.20
21 Manganese Dioxide Electrode MO01 Manganese-based or Vanadium-based Material 100  80.00% 5.00  /
22 Zinc Negative Electrode ZA01 Pure Zinc Powder / Alloy Zinc Powder / 70.0%–96.0% 5.0–15.0 /

MOQ for Custom Small Electrode Sheets: 10*10cm/pcs，5cs/pack，1pack

To place an order or request a quotation, please Contact Us.



This product must be tested according to Canrd recommended testing methods and electrolytes to achieve the desired performance.

Because testing methods and electrolytes significantly impact battery performance, changing the testing method or electrolyte may degrade electrode performance. Please verify this information before purchasing.



Electrode Sheet Technical Data Sheet (SC02XX - Si/C 420 Electrode)

Parameter Specification
Slurry Areal Density (mg/cm²) 7.25
Electrode Sheet Size 10 × 10 cm
Current Collector Thickness (μm) 9 (Carbon-coated Cu foil)
Active Material Ratio 95.00%
Compacted Density (g/cc) 1.10 (Not compacted; value needs self-calculation)
Active Material Si/C 1800 (5%) + Graphite (95%)
Recommended Electrolyte KLD-Si01
Electrode Name Si/C 420 Electrode
Electrode Code SC02XX
Specific Capacity (mAh/g) 420 (0.005–2.000 V)
Areal Capacity (mAh/cm²) 1.9
Coating Areal Density (mg/cm²) 4.80 (Tolerance ±2.0%)



Usage Recommendations

  1. If the electrode is not compacted, it should be compacted before punching and baking. (Reference minimum value above for compacted density.)

  2. Baking conditions: 85–105°C for 4 hours.
    If vacuum baking, replace the air twice.

  3. Active material mass should be weighed for each circular electrode individually for accurate calculation.

Compatible Full Cell Electrode Models (N/P Ratio ≈ 1.09)

SY13XX, SY25XX, SY33XX, LF06XX, LC02XX

Test Conditions

  • Ambient temperature: 25°C, rest for 4 h

  • Discharge: 0.10C / 0.09C / 0.08C / ... / 0.01C (constant current) to 0.005 V

  • Rest for 3 min

  • Charge: 0.1C (constant current) to 2.00 V

  • Rest for 3 min

Shelf Life

  • 6 months in vacuum-sealed storage

  • Use within 1 month after opening

Capacity Measurement Conditions

  • 25°C

  • 0.10 / 0.09 / 0.08 / 0.07 / 0.06 / 0.05 / 0.04 / 0.03 / 0.02 / 0.01 C DC discharge to 0.005 V

  • 0.1 C CC charge to 2.00 V

This product must be tested according to Canrd recommended testing methods and electrolytes to achieve the desired performance.

Because testing methods and electrolytes significantly impact battery performance, changing the testing method or electrolyte may degrade electrode performance. Please verify this information before purchasing.

Electrode Sheet Technical Data Sheet (SC02XX - Si/C 420 Electrode)

Parameter Specification
Slurry Areal Density (mg/cm²) 7.25
Electrode Sheet Size 10 × 10 cm
Current Collector Thickness (μm) 9 (Carbon-coated Cu foil)
Active Material Ratio 95.00%
Compacted Density (g/cc) 1.10 (Not compacted; value needs self-calculation)
Active Material Si/C 1800 (5%) + Graphite (95%)
Recommended Electrolyte KLD-Si01
Electrode Name Si/C 420 Electrode
Electrode Code SC02XX
Specific Capacity (mAh/g) 420 (0.005–2.000 V)
Areal Capacity (mAh/cm²) 1.9
Coating Areal Density (mg/cm²) 4.80 (Tolerance ±2.0%)

Usage Recommendations

  1. If the electrode is not compacted, it should be compacted before punching and baking. (Reference minimum value above for compacted density.)

  2. Baking conditions: 85–105°C for 4 hours.
    If vacuum baking, replace the air twice.

  3. Active material mass should be weighed for each circular electrode individually for accurate calculation.

Compatible Full Cell Electrode Models (N/P Ratio ≈ 1.09)

SY13XX, SY25XX, SY33XX, LF06XX, LC02XX

Test Conditions

  • Ambient temperature: 25°C, rest for 4 h

  • Discharge: 0.10C / 0.09C / 0.08C / ... / 0.01C (constant current) to 0.005 V

  • Rest for 3 min

  • Charge: 0.1C (constant current) to 2.00 V

  • Rest for 3 min

Shelf Life

  • 6 months in vacuum-sealed storage

  • Use within 1 month after opening

Capacity Measurement Conditions

  • 25°C

  • 0.10 / 0.09 / 0.08 / 0.07 / 0.06 / 0.05 / 0.04 / 0.03 / 0.02 / 0.01 C DC discharge to 0.005 V

  • 0.1 C CC charge to 2.00 V

This product must be tested according to Canrd recommended testing methods and electrolytes to achieve the desired performance.

Because testing methods and electrolytes significantly impact battery performance, changing the testing method or electrolyte may degrade electrode performance. Please verify this information before purchasing.

Electrode Sheet Technical Data Sheet (SC02XX - Si/C 420 Electrode)

Parameter Specification
Slurry Areal Density (mg/cm²) 7.25
Electrode Sheet Size 10 × 10 cm
Current Collector Thickness (μm) 9 (Carbon-coated Cu foil)
Active Material Ratio 95.00%
Compacted Density (g/cc) 1.10 (Not compacted; value needs self-calculation)
Active Material Si/C 1800 (5%) + Graphite (95%)
Recommended Electrolyte KLD-Si01
Electrode Name Si/C 420 Electrode
Electrode Code SC02XX
Specific Capacity (mAh/g) 420 (0.005–2.000 V)
Areal Capacity (mAh/cm²) 1.9
Coating Areal Density (mg/cm²) 4.80 (Tolerance ±2.0%)

Usage Recommendations

  1. If the electrode is not compacted, it should be compacted before punching and baking. (Reference minimum value above for compacted density.)

  2. Baking conditions: 85–105°C for 4 hours.
    If vacuum baking, replace the air twice.

  3. Active material mass should be weighed for each circular electrode individually for accurate calculation.

Compatible Full Cell Electrode Models (N/P Ratio ≈ 1.09)

SY13XX, SY25XX, SY33XX, LF06XX, LC02XX

Test Conditions

  • Ambient temperature: 25°C, rest for 4 h

  • Discharge: 0.10C / 0.09C / 0.08C / ... / 0.01C (constant current) to 0.005 V

  • Rest for 3 min

  • Charge: 0.1C (constant current) to 2.00 V

  • Rest for 3 min

Shelf Life

  • 6 months in vacuum-sealed storage

  • Use within 1 month after opening

Capacity Measurement Conditions

  • 25°C

  • 0.10 / 0.09 / 0.08 / 0.07 / 0.06 / 0.05 / 0.04 / 0.03 / 0.02 / 0.01 C DC discharge to 0.005 V

  • 0.1 C CC charge to 2.00 V
