316L Stainless Steel CR2032 Coin Cell Case Kit (4-Piece Set)

$36.25

名前

仕様

✓ 選択中: 316L CR2032+gasket 15.5*0.5mm+wave spring 15.4*1.0mm / 316L CR2032+spacer 15.5*0.5mm+wave spring 15.4*1.0mm (100 sets)

数量

品質保証

工場直販

世界規模の配送

Details

概要

仕様

詳細

This product is developed for assembling CR2032 coin cells in laboratory-scale battery research and energy material testing. Manufactured from 316L stainless steel, the shell offers enhanced corrosion resistance and durability, making it suitable for consistent electrochemical testing environments. The set includes a negative shell, spacer, and spring (wave or funnel type) in various thickness combinations to accommodate different electrode stack configurations. Key components are pre-cleaned with professional solvents prior to shipment, allowing direct use without additional washing steps. The 316L CR2032 housing is commonly employed in studies requiring reliable cell casing for evaluating electrode materials, electrolytes, and battery performance metrics such as cycle life and rate capability.

316L Material Button Battery Shell/CR2032 Button Battery Shell

Made of high-quality 316 stainless steel, suitable for battery production.

Battery cover (negative shell), spring sheet, gasket cleaning suggestions:

1. Choose alkaline or neutral solvent (such as deionized water) for ultrasonic cleaning for 10-20 minutes;

2. Use deionized water for ultrasonic cleaning 2-3 times, 1-2 minutes each time;

3. Drying.

Positive shell cleaning suggestion (not recommended for ultrasonic cleaning, easy to scratch each other):

1. Choose alkaline or neutral solvent (such as deionized water) for soaking for 10-20 minutes;

2. Rinse with deionized water 2-3 times, 1-2 minutes each time;

3. Drying.

Note:

Canrd button battery shell, button battery cover, spring sheet, and gasket have been cleaned with professional solvents before shipment and can be used directly without cleaning.

316 positive and negative shell models are CR2025/CR2032 optional;
316 gasket specifications are 15.5*0.5/15.8*0.5/15.8*1.0/16.2*0.5/16.2*0.8mm optional;
316 wave spring has: wave spring 15.4*1.0mm;
316 funnel spring has: funnel spring 15.4*1.1mm and funnel spring 13.0*1.8mm optional;

Due to a wide range of specifications, it is impossible to list them all. If the package you need is not in the list, please note the actual requirements when placing the order and inform customer service to change the product order content.
