Solid-State Mold Battery Test Leads / Blue Banana Plug Test Cable

This product is designed for reliable electrical connection in solid-state battery testing, featuring blue banana plug test cables with a 3.0mm diameter head. Rated for continuous operation from -20°C to 80°C and currents up to 5A, these leads are optimized for use with Blue Electric charge/discharge systems and KELUD temperature chambers—note that polarity must be reversed when used with Xinwei equipment due to opposite terminal sequences. All cabinet-side connectors are GX16-4 female plugs, ensuring standard compatibility. Common applications include routine capacity cycling, impedance measurement, and environmental aging tests for solid-state mold battery cells. With available lengths of 0.3m, 1m, and 2m, these cables meet the electrical and thermal demands of laboratory battery research while maintaining stable contact resistance.

---

Product Introduction:

1. Temperature range of the test leads: -20℃~80℃

2. Suitable for Blue Electric charging and discharging equipment and KELUD constant temperature chambers (if used with Xinwei equipment, the positive and negative terminals of the battery need to be reversed; the positive and negative terminal sequence of Xinwei test leads is the opposite of this product);

3. All female connectors for connecting to the test cabinet use GX16-4 female connectors;

4. The test leads are suitable for a current of ≤5A. If a higher current is required, new test leads need to be custom-made;

5. Custom orders of different specifications start from 80 pieces.

---
